Bottom Loading Furnace

Bottom Loading Furnace
Price : ₹ 3.1 Lac / Piece
Get Best Price

MOQ : 1 Piece(s)

Business Type : Manufacturer, Exporter

Product Details

Maximum Operating Temperature 1200/1400/1600/1800°C
Heating Element Kanthal A1/Silicon Carbide/MoSi2
Temperature Controller Microprocessor based PID controller
Bottom Lifting Arrangement Bottom lifting plate fitted with DC motor ensure smooth lifting & lowering.
Downlaod View

Additional Information

Port Mumbai
Payment Terms T/T
Delivery Time 8-10 Weeks

Preferred Buyer From

Location Worldwide

Bottom loading furnaces are designed for uniform thermal distribution inside the chamber, easy loading and unloading of the sample with help of lifting arrangement. Bottom loading furnaces are ideal to achieve a variety of heating-cooling cycles without sacrificing temperature uniformity or product quality. These furnaces are well suited for calcining, firing and sintering oxide ceramic parts (i.e., alumina, zirconia), technical ceramics, co-fired substrate materials, capacitors, filters, thermistors, ferrites.

The high-temperature bottom loading furnace sare additionally equipped with a drying as well as a forced cooling function. For residual drying, the oven remains open gapwise during heating up to a defined temperature and thus ensures reliable removal of moisture. For accelerated cooling, the furnace is automatically opened step by step under program control.


Yes! I am interested

Submit Your Requirement


Technical Specification 01

Maximum Temperature 1800 oC
Working Chamber* 120(W) X 120(D) X 120(H) mm
Controller P I D based programmable controller
Controlling sensor Thermocouple “B” type
Heating element “U” MoSi2 Heating element
Insulation Multiple layers of high temperature fiber insulation boards ensure
minimum heat loss.
Time to reach max 1.5 Hr temperature
Temperature uniformity Approx +/- 5oC
Bottom lifting arrangement Bottom lifting platform with D.C motor ensures smooth lifting with
speed approx 10 mm/sec.
Total lift movement Approx 200mm
Outer Construction CRCA sheets duly powder coated
Power supply 230V AC, 50 Hz

Technical Specifications 02

Model Maximum
Temperature(oC)
Internal Dimension*
(HXWXD) (mm)
External Dimension
(HXWXD) (mm)
Controlling
Thermocouple
Heating
Element
BLF - 1200 1200 120X120X120
* Customized  hamber
size available on request.
1010X600X595 N Kanthal A1
BLF - 1500 1500 1010X600X595 R Silicon Carbide
BLF - 1800 1800 1010X600X595 B MoSi2
