CALsys -15/110 Peltier Based Temperature Calibrator

CALsys -15/110 Peltier Based Temperature Calibrator
Price : 1.30 Lac / Piece
Get Best Price

MOQ : 1 Piece(s)

Business Type Manufacturer, Exporter, Supplier, Retailer, Wholesaler
Standard CE Certified
Temperature Range -15 to 110°C
Stability ±0.03°C at -15°C, ±0.05°C at 0°C, ±0.07°C at 110°C
Click to view more

Preferred Buyer From

Location Worldwide

Product Details

Uniformity
±0.05°C at -15°C, ±0.07°C at 0°C, ±0.09°C at 110°C
Temperature Resolution
0.1°C
Time to Reach Min. Temp
25 Mins
Controlling Sensor
Precision PRT
Insert Construction
Dia 24x120 mm long, 3x6 mm hole with 115mm insertion depth
Method of control
Digital self tuned PID Controller
Computer Interface
RS - 232
Operating Temperature
20 to 25°C
Power Requirement
230 VAC, 500W
Dimensions
380(H) x 170(W) x 188(D) mm
Instrument Weight
60 Kg
Download
Payment Terms
T/T
Delivery Time
4-6 Weeks

CALsys -15/110 offers medium temperature range from -15°C to 110°C. It is highly stable standard temperature source for calibrating RTD/Thermocouple.

It has Peltier elements to generate stable temperatures in the well. The comparison volume is a metallic block of aluminum, which has a diameter of 24mm and 120mm length.

Key Features:

  • High Stability
  • Portability
  • PC Interfacing
  • Simple to use and cost-effective


Accessories:

  • Reference standard PRT
  • NABL accredited calibration certificate - 3 point
  • Software - cal soft including for setting bath temperature and monitoring the PV. graphical representations of PV/time with 2 hours data logging.
  • Operational manual
  • Carry case

Yes! I am interested


Specification

Temperature Range 15 to 110oC
Temperature Resolution 0.1oC
Stability ± 0.03oC at-15oC
±0.05oC at 0oC
±0.07oC at 110oC
Uniformity ±0.05oC at -15oC
±0.07oC at 0oC
±0.09oC at 110oC
Controlling Sensor Precision PRT
Method of Control Digital self tuned PID Controller
Removable Insert Construction Dia 24 x 120 mm
long, 3 x 6 mm hole with 115mm insertion depth
Time to Reach Max/Min Temp 25 Mins
Operating Temperature 20 to 25oC
Computer Interface RS - 232
Power Requirement 230 VAC, 500 W
Dimensions 380(H) x 170(W) x 188(D) mm
Weight Approx 14 Kg
