CALsys -35/200 High Stability Bath

CALsys -35/200 High Stability Bath
Price : ₹ 2.25 Lac / Piece
Get Best Price

MOQ : 1 Piece(s)

Business Type : Manufacturer, Exporter, Supplier, Retailer

Product Details

Temperature Range -35 to 200°C
Stability ±0.01°C at -35°C, ±0.05°C at-0°C, ±0.04°C at 200°C
Uniformity ±0.03°C at -35°C, ±0.06°C at 0°C, ±0.07°C at 200°C
Resolution 0.01°C
Cooling Time 60 min (room temperature to -35°C )
Volume 6 Ltr
Access Opening 105 (L) x 105 (W) mm
Immersion Depth 150 mm
Method of control Digital Self Tuned PID Controller
Computer Interface RS - 232
Power Requirement 230 VAC, 2 KW (50 Hz)
Dimensions 540(H) x 220(W) x 620(D)mm
Weight 65 Kg
Calibration Accredited calibration certificate provided
Environmental operating conditions 0°C to 40°C, 0% to 90% RH (non-condensing)
Specifications valid in environmental conditions 13°C … 25°C
Input (CaLsys -35/200 Autocal) Four Channels (One master and three test sensors), high-quality LEMO connector suitable for both T/C
Download View

Additional Information

Payment Terms T/T
Delivery Time 6-8 Weeks

Preferred Buyer From

Location Worldwide

CALsys -35/200 is a Highly Stable Stirred Liquid Bath for Calibration RTD / Thermocouple and also for compensation of cold junction.

CALsys -35/200 offers the temperature range of -35 to 200°C. It has large tank which is filled with liquid (Water+Methanol/Silicon Oil). The liquid is heated or cooled to the desired temperature, where Methanol+Water are used for Negative Temperature and Silicon Oil is for Heating purpose.

It has better stability & uniformity than dry block bath and as it uses of stirred liquid. This CALsys -35/200 is built using CFC-free refrigerants.

Key Features:

  • High Accuracy
  • High Stability and Uniformity
  • Wide Temperature Range
  • PC Interfacing
  • Simple to Use and Cost-Effective


Accessories
Standard Accessories

  • Reference Standard PRT…Part No.TPRT-A-300
  • NABL accredited calibration certificate - 3 point
  • Software - Including for setting bath temperature and monitoring the PV. Graphical representations of PV/TIME.
  • Operational Manual


Optional Accessories

  • Methanol............10 Ltr. No.(3050-M)
  • Silicon Oil............10L Part No.C200S-LB SO



Input (CaLsys -35/200 Autocal): Four Channels (One master and three test sensors), high-quality LEMO connector suitable for both T/C and Rtd.

Software (CaLsys -35/200 Autocal): The calibrator will be provided with software for data recording (Manual Mode) and report generation in Auto Mode.

Data Logging (CaLsys -35/200 Autocal): Data Logging facility with logged data export to the computer through  LAN port (Optional USB)


Yes! I am interested

Submit Your Requirement


Specification

Temp Range 35 to 200oC
Stability ±0.01oC at -35oC (Methanol)
±0.05oC at-0oC (Methanol)
±0.04oC at 200oC (Silicon Oil)
Uniformity ±0.03oC at -35oC
±0.07oC at 0oC
±0.07oC at 200oC
Temperature Resolution 0.01oC
Time to Reach Max Temp 1.5 Hrs
Medium Cooling Methanol + Water
Medium Heating Silicon Oil
Controlling Sensor PT-100
Volume 7 Ltr.
Access Opening 157(L) x 142(W)
Depth 127 mm
Method of Control Digital self tuned PID Controller
Computer Interface RS - 232
Operating Temperature 20 to 25oC
Wetted Part SS-304
Power Requirement 230 VAC, 2.0 KW
Dimensions 540(L) x 220(W) x 620(H)mm
Weight Approx 41 Kg
