High Stability Block Furnace (CALsys 1500L)

Home › Products › Calibration Equipment › High Temperature Dry Block Calibrator › High Stability Block Furnace (CALsys 1500L)

High Stability Block Furnace (CALsys 1500L)
High Stability Block Furnace (CALsys 1500L)
Price : 4.19 Lac / Piece
Get Best Price

MOQ : 1 Piece(s)

Business Type Manufacturer, Exporter, Supplier, Retailer, Wholesaler
Standard CE Certified
Temperature Range 500 to 1500°C
Temperature Resolution 1.0°C
Click to view more

Preferred Buyer From

Location Worldwide
Request to Call Send Enquiry

Product Details

Stability
±0.4°C at 500°C, ±0.7°C at 1000°C, ±1.0°C at 1500°C
Uniformity
±0.6°C at 500°C, ±0.8°C at 1000°C, ±0.6°C at 500°C ±0.8°C at 1000°C ±1.2°C at 1500°C
Controlling Sensor
PT-RH/PT T/C
Method of Control
Digital Self Tuned PID controller
Insert Construction
Dia 37 x 245 mm long (2X6mm & 2X8 mm holes) of 140mm insertion depth
Time to Reach Max Temperature
2 Hrs
Computer Interface
RS - 232
Operating Temperature
20 to 45°C
Power Requirement
230 VAC, 3.0 KW
Dimensions
500(H) x 450(W) x 530(D) mm
Weight
55 Kg(without packing)
Download
View
Payment Terms
T/T
Delivery Time
6-8 Weeks

CALsys 1500L calibration source is a highly stable standard furnace for calibrating thermocouples in the laboratory. The temperature of the furnace is set and controlled by a self-tuned PID controller with automatic super fine adjustment. The standard insert is a Ceramic Tube, which is 37 mm in diameter with 245 mm long and can hold up to four thermocouples.

It has been designed for high-temperature range calibration and find application in the glass, electrical power, automotive & material processing industries and laboratories.

Key Features:

  • Use of Silicon Carbide Spiral Rod Heaters
  • Large Immersion Depths
  • Wide Operating Range (500 to 1500°C)
  • High Stability
  • PC interfacing
  • Simple to Use and Cost-Effective


Accessories:

  • NABL accredited calibration certificate - 3 point
  • Software - Cal Soft including for setting bath temperature and monitoring the PV. Graphical representations of PV/TIME with 2 hours data logging.
  • Operational Manual

Yes! I am interested


Specification

Temperature Range `500 to 1500oC
Temperature Resolution 1.0oC
Stability ±0.4oC at 500oC
±0.7oC at 1000oC
±1.0oC at 1500oC
Uniformity ±0.6oC at 500oC
±0.8oC at 1000oC
±0.9oC at 1500oC
Controlling Sensor PT-RH/PT T/C
Method of Control Digital self tuned PID Controller
Insert Construction Dia 37 x 245 mm long
(2X6mm & 2X8 mm holes) of 140mm insertion depth
Heaters Silicon Carbide Spiral Rod Heater
Time to Reach Max Temp 2 Hrs
Computer Interface RS - 232
Operating Temperature 20 to 45oC
Power Requirement 230 VAC, 3.0 KW
Dimensions 570(H) x 450(W) x 520(D) mm
Weight 55 Kg
