Non Contact Pyrometer (AST EL50H)
| Business Type | Manufacturer, Exporter, Supplier, Retailer, Wholesaler |
| Downlaod |  View |
Preferred Buyer From
| Location | Worldwide |
EL50-H is a digital Pyrometer in economic range with extended sensor head in 4 wire technology, for non-contact temperature measurement between 0oC to 800oC.The sensor head is unaffected by electromagnetic interferences. The pyrometer sensor head is specially designed to withstand ambient temperature upto 180oC without cooling.
Details :
- The pyrometer is equipped with a Inbuilt 4 digit LCD display which offers many signal processing features. The electronic box with integrated Keypad helps in setting parameters like Emissivity,Analog Sub range,Set point,Hysteresis (Hyst),Analog Output,Unit of temp(°C or F),Response Time,Peak Picker and Sensor address etc. Analog outputs options available are 4…20mA, 0…20mA, 0…10V, Thermocouple type “K” or “J” (userselectable) via keypad or software. RS- 232/RS-485 serial interface card is available as optional.
- EL50-H is provided with USB 2.0 output and PC software. The pyrometer can be powered through USB port. In this case no external power supply is required. 24 V DC is required for operation of Analog Output, RS - 232 & RS - 485 & Relay Output.
Features :
- Power supply (12V DC to 28 V DC) with reverse polarity protection
- Sensor head can withstand ambient temperature upto 180°C
- Spectral range 8 μm...14 μm
- Wide temperature ranges (0oC to 800oC)
- Inbuilt LCD Display and Keypad for parameterisation
- Fast response time within milliseconds
- Analog output like 4…20mA, 0…20mA, 0…10V, Thermocouple type “K” or“J” (user selectable)
- USB2.0 Digital output and RS-232/RS-485 Serial interface card
- Relay output
- User friendly PC software for communication
Standard Scope of Supply :
- Pyrometer with LCD Display
- Keypad for parameterizing,
- Extended sensor head with 3m cable
- USB 2.0 Digital output, USB Cable
- Relay Output
- Analog output 4…20mA, 0…20mA, 0…10V, Thermocouple Type “K” or “J” (user selectable)
- Calibration certificate, Software & operation manual
Optional :
- Mechanical and Electrical Accessories
- RS-232 & RS-485 serial interface card
- Extra Cable Lengths
Applications :
- Plastic, Rubber & Ceramic Fluids
- Paper Oxide/Painted metal surface,
- Textile Wood and Glass Industries
Product Feature :
- Digital pyrometer with extended Sensor head. Analog and digital output, USB 2.0 Output, Inbuilt LCD, Laser Targeting & keypad for parameterization FOR Hot Environment UPTO 180oC
Temperature Range : 0oC - 800oC
Technical Specification
| Model | EL50-H |
| Temperature Range(Analog sub-range adjustable) |
0oC….800oC |
| Spectral Range | 8…14 μm |
| Photodetector Type | Thermopile |
| Distance to Spot Size Ratio | 2:1 15:1 (To be specified while ordering) |
| Emissivity (ε) | 0.1….1.2 adjustable |
| Response Time | 60 msec adjustable upto 10 sec |
| Accuracy | ±1.5% of the measured value or 3oC whichever is greater (The sensor head must be at constant ambient temperature for a minimum of 15 minutes) |
| Repeatability | 0.3% of reading in oC + 1oC |
| Analog Output | 0-20mA, 4-20mA, 0-10V, Thermocouple Type “K” or “J” (User selectable) |
| Digital Output | USB 2.0 RS-232/RS-485 interface card (Optional) *At a time only one digital output possible |
| Operating Temp. Range | Electronic box upto 70oC Sensor head upto 180oC |
| Storage Temp. Range | -20oC…70oC |
| Relay Output | Relay Output with hysteresis 60V DC/42V AC RMS, 0.4A |
| Adjustable Parameters and Features via Software |
Emissivity, Response Time, Clear Time (Peak Picker), Analog Output, Analog Scale (Sub Range), Unit Of Temperature (oC/oF), Communication mode(Comm. mode), Record feature etc. |
| Adjustable Parameters and Features via Keypad |
Emissivity, Setpoint, Hysteresis (Hyst), Analog Sub Range, Analog Output, Unit of temperature, Sensor address, Response Time, Clear Time(Peak Picker) etc. |
| Power Supply | 12V DC to 28 V DC with reverse polarity protection |
| Power Consumption | Max 2.5 watt |
| Protection Class | IP65 |
| Housing | Sensor head-Stainless Steel Electronic Box - Zinc |
| Isolation | Power supply, *Digital output and Analog output are galvanically islolated against each other * Not applicable for USB 2.0 digital output |
| Operating Humidity | 10-95%, non condensing conditions |
| Weight & Dimensions | 600g 112.5mmx82.5mmx33mm(L x W x H) |
